DESCRIPTION
STOCK INJECTOR POWER FLASH STAGES
| Stage | HP (crank) | HP (wheel) | Wastegate Crack Pressure (lbs.) | Boost (psi) | Fuel (octane) | Recommended Exhaust |
| Stock | 172 | 141 | 7 | 14 | 91 | N/A |
| Stage 1 | 192 | 157 | 7 | 16 | 91 | Stock or Aftermarket |
| Stage 2R | 196 | 161 | 8 | 17 | 91 | Stock or Aftermarket |
| Stage 3R | 200 | 164 | 8 | 17.5 | 91 | Stock or Aftermarket |
| Stage 3R-93 | 205 | 168 | 8 | 18 | 93 | Stock or Aftermarket |
BIG INJECTOR POWER FLASH STAGES
| Stage | HP (crank) | HP (wheel) | Wastegate Crack Pressure (lbs.) | Boost (psi) | Fuel (octane) | Recommended Exhaust |
| Stage 3RWi | 205 | 168 | 8 | 18 | 93 | N/A |
| Stage 4RWi | 215 | 176 | 9 | 20 | 95 | Stock or Aftermarket |
| Stage 4x100 | 225 | 184 | 11 | 22 | 100 | Stock or Aftermarket |
| Stage 5x85 | 235 | 193 | 11 | 22 | E85 | Stock or Aftermarket |
| Multi-Map Stage 4RWi-MM | 200/215 | 164/176 | 9 | 20 | 91/95 | Stock or Aftermarket |
CodeShooter flashes the ECU via the vehicle diagnostic port. App-driven color touchscreen. Features datalogging, monitoring, and code read/reset. Optional Plug-n-Play AFR module for real-time AFR monitoring. Vehicle can be returned to stock.
Charts above list performance expectations and equipment requirements where applicable.
CodeShooter is an app-based application compatible with most Android or iOS devices.
FITMENT
2018-2021 Can-Am Maverick X3 Turbo R (172HP - all models)
Manufactured by Evolution Powersports. Official specs and resources: EvoPowersports.com.
